The Art Diffusion line consists of over 150 architectural wall panel patterns that offer a dramatic alternative to traditional flat wall panels. Our sculpted and carved panels contain architectural elements such as waves, ornamental textures, modular repeating patterns and continuous patterns.

Resources

  • Over 150 patterns to choose from and custom made to order
  • Standard panel sizes 4′ x 8′ and can be custom sized
  • The standard core material is IDF (proprietary High-Density Fiberboard)
  • Other cores available according to project requirements including solid color MDF
  • Finish options: Raw, primed and sanded, factory finishes offered or specified paint finishes
  • Custom designs welcomed
  • Samples available upon request
  • Made in the USA

The Art Diffusion line consists of over 150 architectural wall panel patterns that offer a dramatic alternative to traditional flat wall panels. Our sculpted and carved panels contain architectural elements such as waves, ornamental textures, modular repeating patterns and continuous patterns.

Resources

  • Over 150 patterns to choose from and custom made to order
  • Standard panel sizes 4′ x 8′ and can be custom sized
  • The standard core material is IDF (proprietary High-Density Fiberboard)
  • Other cores available according to project requirements including solid color MDF
  • Finish options: Raw, primed and sanded, factory finishes offered or specified paint finishes
  • Custom designs welcomed
  • Samples available upon request
  • Made in the USA

No resources available at this time. Contact our office for available resources on specific products.
Gallery
No images found.
Frequently Asked Quesitons
What core materials are available for CNC panels?
  • CNC panels come in various core material options, including:
    • IDF (Interlam® Designed Fiberboard) – High-quality wood fibers for deep profiling.
    • NAF (No Added Formaldehyde) – Environmentally friendly with ultra-low formaldehyde emissions.
    • Class A Fire Rated MDF – MDF treated with fire-retardant additives.
    • Moisture Resistant MDF – Ideal for high-humidity interior applications.
    • Forescolor – Through-colored engineered wood available in multiple colors.
    • FSC® Certified MDF – Sustainable and responsible wood sourcing.
What sizes and thicknesses are available for CNC panels?
  • Standard panel size: 48” x 96” (4’ x 8’)
  • Custom sizes up to 60” wide and 120” long may be available.
  • Thickness ranges from ½” to 3” depending on pattern and installation method.
Can CNC panels be customized with different patterns and finishes?
  • Yes, CNC panels can be customized with a variety of patterns and finishes, including:
    • Factory Sanded & Primed – Ready for on-site finishing.
    • Painted (Benjamin Moore & Sherwin Williams colors)
    • Specialty Paints – Metallic, antique, oxy, tortoise shell.
    • Foil Overlays – Non-gloss and high-gloss options.
    • High-Pressure Laminates (Lab Design Laminates)
How should CNC panels be installed?
  • CNC panels can be installed using different methods:
    • Z-Clips – Requires at least three rows of Z-clips for proper support.
    • Construction Mastic (Liquid Nails, PL Premium Polyurethane) – Recommended for plywood surfaces.
    • Direct Screw Attachment – Panels can be screwed directly into a structural backer.
How do I prevent warping or bowing of panels?
  • Store panels flat and face up in a climate-controlled environment before installation.
  • Allow at least three days for acclimation to the environment.
  • Maintain relative humidity levels between 25-55% to avoid expansion or contraction.
  • Use back priming or sealing to prevent moisture absorption.
Can CNC panels be installed on drywall?
  • It is not recommended to install CNC panels directly on drywall. A structurally sound surface, such as 12mm Baltic birch plywood, is advised for secure adhesion.
How do I clean and maintain CNC panels?
  • Metal Finishes: Use tarnish removers and metal polishes; apply a protective wax after cleaning.
  • Painted Finishes:
    • Use a soft, dry cloth for dusting.
    • Lightly dampen a cloth with mild soap and water for cleaning.
    • Avoid silicone-based cleaners and harsh detergents.
  • Foil (Membrane) Finishes: Use a soft, dry cloth or vacuum with a soft brush attachment.
  • Rusty Steel Finish: Do not use damp cloths or solvents, as this can cause permanent streaking.
Can CNC panels be repainted or refinished?
  • Yes, CNC panels can be repainted or refinished. However:
    • Factory finishes should be lightly sanded before repainting.
    • Lacquer or water-based paints should be used for optimal adhesion.
What is the lead time for CNC panel orders?
  • Standard lead time is 2 to 4 weeks, depending on workload. Lead times are based on a first-come, first-served basis and may vary for custom orders.
Do you offer rush orders?
  • No, rush orders are not available. However, orders are processed as quickly as possible.
What information is needed for custom CNC panel orders?
  • For custom projects, please provide:
    • Core material selection (IDF, NAF, Fire-Rated, etc.).
    • Pattern choice and orientation (vertical or horizontal).
    • Panel dimensions and thickness.
    • Finish preference (painted, foil overlay, laminate, etc.).
    • Installation method (Z-clips, mastic, direct screw attachment).
    • Project layout in AutoCAD (.DWG, .DXF, or PDF format) for precise cutting.
